Low Profile S Type Load Cell for Bin Weighing
The Weighing load cell is a force sensor. Sensors are devices that convert the form of energy into readable electrical signals. In this case, the weighing load cell converts the force into voltage, which can be read by electrical equipment.
Weighing load cell, respectively are single point load cell, cantilever beam load cell, column load cell, S beam load cell, spoke load cell. Weighing load cell made of stainless steel or alloy steel material, German technology, high precision, anti-bias load ability, strong impact resistance; Easy to install, high level of protection. Applicable to electronic scale, counting scale, electronic balance, packaging scale, hopper scale, industrial weighing instrument, industrial weighing system and so on.
| Specifications | Technique | Specifications | Technique |
| Capacity | 50,100,200,300,500kg, 1,2,3,5t | Insulation | ≥5000MΩ/100VDC |
| Rated output | 2.0±1%mV/V | Recommended excitation | 5~12V |
| Zero balance | ±2%mV/V | Maximum excitation | 15V |
| Non-linearity | ≤0.02%F.S. | Compensated temp range | -10~40ºC |
| Hysteresis | ≤0.02%F.S. | Operation temp range | -20~75ºC |
| Repeatability | ≤0.02%F.S. | Safe overload | 150%F.S. |
| Temp.effect on output | 0.02%F.S./10ºC | Ultimate overload | 500%F.S. |
| Temp.effect on zero | 0.02%F.S./10ºC | Cable size | 5m |
| Input impedance | 350±100Ω | Material | Alloy Steel |
| Output impedance | 300±5Ω | | |
Xi'an Ruijia Measuring Instruments Co., Ltd. is a manufacturer of force sensors and related products, dedicated to providing high-quality solutions for various industries. With a commitment to innovation, reliability, and precision, we have established ourselves as a trusted partner for businesses worldwide.
Founded in 2005, we have accumulated years of experience in the field of weighing technology, enabling us to deliver products tailored to our customers' needs. Our product range includes a comprehensive selection of load cells, weighing modules, controllers, systems, and software solutions. We offer a diverse array of weighing products suitable for industrial automation, logistics, transportation, healthcare, retail, and more.
At Xi'an Ruijia Measuring Instruments Co., Ltd., we pride ourselves on our technological expertise and dedication to continuous improvement. Our team of skilled engineers is committed to developing innovative solutions that push the boundaries of weighing technology, ensuring our products meet the highest standards of performance and accuracy. We serve a global clientele, catering to diverse market sectors across the globe. Our products are utilized by businesses of all sizes, from small enterprises to multinational corporations, in both domestic and international markets.
Quality is at the core of everything we do. We adhere to stringent quality control measures throughout the manufacturing process to ensure that our products meet or exceed industry standards. Our commitment to quality has earned us a reputation for reliability and excellence among our customers. Besides, customer satisfaction is our top priority. We offer comprehensive customer service and support, including technical consultation, pre-sales assistance, and after-sales service, to ensure a seamless experience for our clients.
With a focus on innovation, quality, and customer satisfaction, Xi'an Ruijia Measuring Instruments Co., Ltd. is your trusted partner for all your weighing sensor needs. Contact us today!
